90° Picatinny Offset Rail Mount (Picatinny Clamp to Vertical Picatinny)

Enables various quick-detach mounting options with the Sightlok RF-1.

Here’s your quick detach mounting procedure:

1. Purchase any 17S clamp from a range of manufacturers including Magpul, RRS, Area419, Leofoto, etc.

2. Bolt your 17S clamp to the Sightlok RF-1

3. Bolt this 90° Picatinny Offset Rail Mount to your picatinny rail

You can now quick detach the Sightlok RF-1 rangefinder mount from your weapon.

INCLUDED:
Comes with 1 M5 bolt

NOT INCLUDED:
Picatinny Lock (needed to close the picatinny clamp) & M5 Thumbscrew are NOT INCLUDED and must be purchased separately

MATERIALS:
6061-T6 Aluminum with MIL-A-8625 spec Type III anodized hard coat finished in matte black.

MOUNT REQUIREMENTS:
Mounts securely to any Picatinny (MIL-STD 1913) or Weaver rail.

MOUNTING CLEARANCE:
The mount requires a minimum of 0.275″ (7mm) of clearance between the top of the rail and the bottom of the scope to mount under the scope.

Weight:
0.88 ounces (25 grams), excluding hardware

LIFETIME WARRANTY:
SIGHTLOK warrants that the Sightlok RF-1 mount you purchase was originally manufactured free of defects in material, workmanship, and mechanical function. For the lifetime of the original purchaser, SIGHTLOK agrees to correct any defect in the mount for the original purchaser by repair, adjustment, or replacement, at SIGHTLOK’s option, with the same or comparable quality components (or by replacing the mount at SIGHTLOK’s option); provided however that a Return Merchandise Authorization (RMA) is first obtained by contacting SIGHTLOK Customer Service.
