Mount your rangefinder to your weapon

The Sightlok RF-1 is a Picatinny / Weaver rail mount that turns the handheld rangefinder you already own into a weapon-mounted laser rangefinder.

See the Sightlok RF-1 $199.95  ·  ★ 4.88 / 5 · 17 reviews
1 / 8

Adjustable Mount

$69.95

This is the standard mount most Sightlok RF-1 users will want. It positions the RF-1 to the right or left of your scope, clamped to the rail.

It enables the Sightlok RF-1 to mount to any standard Picatinny rail. The height, length, and width (offset from the picatinny rail) are all adjustable.

INCLUDED:
Comes with 2 M5 bolts (1 for each offset), 4 MLOK T-nuts and bolts (M5-10mm), a Picatinny Lock (needed to close the picatinny clamp) and an M5 Thumbscrew

MATERIALS:
6061-T6 Aluminum with MIL-A-8625 spec Type III anodized hard coat finished in matte black.

MOUNT REQUIREMENTS:
The Sightlok RF-1 mounts securely to any Picatinny (MIL-STD 1913) or Weaver rail.

MOUNTING CLEARANCE:
The mount requires a minimum of 0.275″ (7mm) of clearance between the top of the rail and the bottom of the scope to mount under the scope. It can also be flipped and mounted to the rail under the scope occular if other mount points are obstructed.

SIZING AND ADJUSTMENT RANGE:
Rangefinder height adjustment (choose between 2 MLOK rails)

Length adjustment: 3 1/8″ (8cm)

Horizontal distance from Picatinny/Weaver rail adjustment (2 different-length options are included)
(Having variable options for horizontal distance from the Picatinny/Weaver rail ensures that the rangefinder laser beam can clear windage/brightness/focus knobs/focus rings on the scope).

Weight:
1.7 to 1.8 ounces (50-54 grams), excluding hardware, depending on offset chosen

LIFETIME WARRANTY:
We will repair or replace your Sightlok product in the event it becomes damaged or defective, at no charge to you. If we cannot repair your product, we will replace it with a product in perfect working order of equal or better physical condition.

THE SIGHTLOK® WARRANTY IS:
– Unlimited Lifetime
– Fully Transferable
– No Warranty Card Required
– No Receipt Required
– No Time Limit Applies
– No Charge

WARNING:

You are attempting to purchase a Sightlok RF-1 mount with no mounting accessories. If you do so, you will only be able to mount it using some non-standard route like bolting it to your MLOK handguard, buying a clamp from a 3rd party, or using it with a tripod. Are you sure you want to do this?
